User’s Guide for DG2000 Series
2-45
To Generate Burst
Burst Function can generate versatile waveforms in burst, which can last specific times
of waveform cycle(N-Cycle Burst), or when the external gated signals( Gated Burst) is
applied, any waveform could be used. But noise can only be used in Gated Burst.
Press Burst button, in the Normal Mode, the operation menu will appear on the bottom
of the screen, see figure 2-58. Set the Waveform parameters by using the operation
menu.
Figure 2-58 The Setting Interface of Burst Waveform
