RIGOL
© 2006 RIGOL Technologies, Inc
User’s Guide for DG2000 Series
1-15
To Use Store/Utility/Help Function
As shown in figure 1-22, there are three buttons on the operation panel, which are
used to call the store/recall, utility and help function. The instruction below will help
you familiarize with these Functions.
Figure 1-22 The Store/Recall, Utility and Help Button
1. The Store/Recall Button is used to store waveform data and configure
information.
2. The Utility Button is used to set the auxiliary system function, change the output
configure parameters, interface setting, system setting information or perform
the instrument self-test and read the calibration information, etc.
3. The Help Button is used to see the help information.
Operation Instruction
To get help：
To get help on any key of the front panel, press the key and last for 1 second, then
the help message will appear.
