User’s Guide for DSA1000 Series IX
DSA1000 Series Overview
DSA1000 Series Spectrum Analyzer is designed with small volume, light weight, high
cost performance, and having an easy-operated keyboard layout. Features include a
high definition 8.5 inch TFT color LCD, easy to understand settings and messages on
the display interface, standard or configurable USB, LAN and GPIB communication
interfaces that enable users to display or control the instrument over virtual terminals
and remote networks. It is widely used in education, science, corporate centers,
industrial production and many other fields.
Main features:
Frequency Range: 9 kHz to 3 GHz
Display Average Noise Level (DANL): -138 dBm
Phase Noise: -80 dBc/Hz @ 10 kHz offset (Typical)
Total Amplitude Accuracy: <1.5 dB
Minimum Resolution Bandwidth: 100 Hz
Standard with EMI Filter and Quasi-Peak Detector
3 GHz Tracking Generator (DSA1030-TG)
Built-in lithium battery (China only), can provide power continuously for three
hours
Plenty of measurement functions and auto settings for choosing
8.5 inches widescreen display, clear and vivid interface, easy-to-use design
Various interfaces such as LAN, USB Host, USB Device, VGA or GPIB (optional)
Compact design with only 13.7 lbs (without battery)
Enhance or expand the functions of analyzer by using the PC software, Ultra
Spectrum
