Rigol DSA1000 Series User Manual

Front Panel Key Reference RIGOL
User’s Guide for DSA1000 Series
2-45
2.3.4.5 Power Range
Sets the power range that can be output from the TG while in power sweep mode,
forming the boundary parameters under the Power Sweep mode together with the TG
Level.
You can use the numeric keys, knob or direction keys to modify this parameter. For
more details, please refer to “Parameter Input”.
Table 2-26 Power Range of TG
Parameter Explanation
Default 0 dB
Range 0 dB to 20 dB
Unit dB
Knob Step 1 dB
Direction Key Step 10 dB
2.3.4.6 Freq Offset
Sets the offset between the TG signal frequency and the current sweep frequency of
the analyzer.
Key Points:
 If a frequency offset is generated from the TG signal passing from the receiver,
you can set this parameter to eliminate it in order to match the displayed
frequency to the TG frequency.
 You can use the numeric keys to modify this parameter, please refer to
“Parameter Input” for more details.
Table 2-27 Frequency Offset
Parameter Explanation
Default 0 Hz
Range -300 MHz to 300 MHz
Unit GHz, MHz, kHz, Hz
Knob Step N/A
Direction Key Step
N/A
