Auto Measurement
MSO5000-E series provides auto measurements for 41 waveform parameters, as well
as the statistics and analysis of the measurement results.
Quick Measurement after AUTO
When the oscilloscope is correctly connected and has detected a valid input signal,
press AUTO to enable the waveform auto setting function and open the auto setting
function menu.
âš« : Press this key, and then the complete single period of the signal is
displayed automatically on the screen. Meanwhile, the system will make
measurements for the "period" and the "frequency" of the currently displayed
waveforms in a complete single period. The measurement results are displayed
at the bottom of the screen.
âš« : Press this key, and then multiple periods of the signal are displayed
automatically on the screen. Meanwhile, the system will make measurements
for the "period" and the "frequency" of the currently displayed waveforms in a
multiple periods. The measurement results are displayed at the bottom of the
screen.
âš« : Press this key, and then one rising edge of the signal is displayed
automatically on the screen. Meanwhile, the system will make measurements
for the "rise time" of the currently displayed rising edge. The measurement
results are displayed at the bottom of the screen. By default, it is intended for
the fast edge signal.
âš« : Press this key, and then one falling edge of the signal is displayed
automatically on the screen. Meanwhile, the system will make measurements
for the "fall time" of the currently displayed falling edge. The measurement
results are displayed at the bottom of the screen. By default, it is intended for
the fast edge signal.
âš« : press this key, and the system returns to the last set menu.
âš« Press Option to enter the auto setting function menu.
➢ Press Lock to lock the AUTO function. To unlock the AUTO function, use the
following two methods:
Method 1: Send the remote command :SYSTem:AUToscale ON to unlock the
AUTO function.
Method 2: Press Lock again, then a password input dialog box is displayed.
Input the password. By default, there is no password, and pressing OK
directly can unlock the function.
