Rigol MSO5000-E Series User Manual

RIGOL Chapter 13 Pass/Fail Test
13-2 MSO5000-E User Guide
To Enable or Disable the Pass/Fail Test Function
Press Utility → PassFail to open the pass/fail test setting menu, or enable the
touch screen and then tap the function navigation icon at the lower-left corner of
the screen to open the function navigation. Then, tap the "Pass/Fail" icon to open the
pass/fail test setting menu.
In the menu, press Enable continuously to enable or disable the pass/fail test
function.
Note: The pass/fail test function cannot be enabled in the following conditions:
when the timebase mode is "XY" or "ROLL"; when the delay sweep is enabled.
To Start or Stop the Pass/Fail Test Operation
After the Pass/Fail test function is enabled, press Operate continuously to start or
stop the test operation.
During the test process, the oscilloscope will test the waveforms, display the test
information, and output the test failure information based on the current settings.
You can set the test mask, the display status of the test information, and the output
form of a failed test based on the selected source channel for the test. Then save the
test mask range to the internal or external memory, and then recall it when needed.
For the details, please refer to the following section.
Note:
⚫ Only when the pass/fail test function is enabled, can you start or stop the
pass/fail test operation, enable or disable the display of the test information,
save and recall the test mask range.
⚫ After starting the test operation, you can neither modify the source channel nor
adjust the test mask.
To Select the Source
Before selecting the source, connect the signal under test to the analog channel
input terminal of the oscilloscope. Press Source and rotate the multifunction knob
to select the desired source channel, and then press down the knob to select it.
You can also press Source continuously or enable the touch screen to select it. The
available source channels include the analog channel (CH1-CH2).
Note: Only the channels that have been enabled currently can be selected.
