Rigol MSO5000-E Series User Manual

Chapter 19 Bode Plot RIGOL
MSO5000-E User Guide 19-7
Display
Press Display continuously to enable or disable the display of the bode plot window.
Save
In the Bode setting menu, press Save to enter the file saving menu. You can perform
the save operation for the bode plot.
File Type
Press File Type to select the file type for saving the bode plot. The available file
types include "*.png", "*.bmp", "*.csv", and "*.html".
Note:
When you select "*.png" and "*.bmp" as the file type, the bode plot will be saved as
a form of waveform. When you select "*.csv" and "*.html", the bode plot will be
saved as a form of chart.
File Name
Press File Name, input the filename for the bode plot in the pop-up numeric keypad.
For details, refer to descriptions in "To Create a Folder".
NewFolder
It is grayed out and disabled in the bode plot setting.
Window
Press Window continuously to show or hide the window of file storage path.
⚫ Show: The window of the file storage path is displayed. You can set the storage
path for the bode plot.
⚫ Hide: The window of the file storage path is hidden.
Save
Press Save to save the bode file according to the save setting.
Connection Diagram
Before enabling the bode function, make a proper loop connection. Press Tips to
view the circuit connection diagram for the bode plot function. Tap the icon at
the upper-right corner of the Tips window to close the window.
