Rockwell Automation Publication 2080-UM002N-EN-E - November 2022 117
Chapter 6 Micro870 Controller Distributed Network Protocol
Implementation Table Micro870 (2080-L70E-24QxBN) controllers supports DNP3 Certification Subset Level 2.
Table 12
identifies which object groups and variations, function codes and qualifiers the
device supports in both requests and responses. The Request and Response columns identify
all requests and responses that may be sent/parsed by a DNP3 Master, or must be parsed/sent
by the controller.
The implementation table lists all functionality required by either DNP3 Master or controller as
defined within the DNP3 IED Conformance Test Procedures. Any functionality beyond the
highest subset level supported is indicated by grayed table cells.
Request 16 (0x10) INITIALIZE_APPL Yes
Controller parses. Clears fault and changes the controller mode to
Remote Program.
Request 17 (0x11) START_APPL Yes
Controller parses. Clears fault and changes the controller mode to
Remote Run.
Request 18 (0x12) STOP_APPL Yes
Controller parses. Changes the controller mode to Remote
Program.
Request 19 (0x13) SAVE_CONFIG No Deprecated
Request 20 (0x14) ENABLE_UNSOLICITED Yes Controller parses
Request 21 (0x15) DISABLE_UNSOLICITED Yes Controller parses
Request 22 (0x16) ASSIGN_CLASS No
Request 23 (0x17) DELAY_MEASURE Yes Controller parses. Used for non-LAN
Request 24 (0x18) RECORD_CURRENT_TIME No Controller parses. Used for LAN
Request 25 (0x19) OPEN_FILE Yes Controller parses
Request 26 (0x1A) CLOSE_FILE Yes Controller parses
Request 27 (0x1B) DELETE_FILE Yes Controller parses
Request 28 (0x1C) GET_FILE_INFO No Controller parses
Request 29 (0x1D) AUTHENTICATE_FILE Yes Controller parses
Request 30 (0x1E) ABORT_FILE No Controller parses
Request 31 (0x1F) ACTIVATE_CONFIG No Controller parses
Request 32 (0x20) AUTHENTICATE_REQ No Controller parses
Request 33 (0x21) AUTHENTICATE_ERR No Controller parses
Response 34 (0x22) RESPONSE Yes Controller sends
Response 35 (0x23) UNSOLICITED_RESPONSE Yes Controller sends
Response 36 (0x24) AUTHENTICATE_RESPONSE No Controller sends
37 (0x25)…47 (0x2F) No Reserved
Table 11 - Function Codes for DNP3 in Micro870 Controllers (Continued)
Message Type Function Code Name Micro870 Support Description
Table 12 - Implementation Table for Micro870 controllers
DNP Object Group & Variation
Request
DNP3 Master may issue
Controller must parse
Response
DNP3 Master must parse
Controller may issue
Group Num Var Num Description Function Codes (dec) Qualifier Codes (hex) Function Codes (dec) Qualifier Codes (hex)
0
211…239
241…243
248…250
252
Device Attribute
1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00 (start-stop)
0
240
245…247
Device Attribute
1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00 (start-stop)
2 (write) 00, 01 (start-stop)
0254
Device Attribute – Non-specific all
attributes request
1 (read)
00, 01 (start-stop)
06 (no range, or all)
0255
Device Attributes – List of attribute
variations
1 (read)
00, 01 (start-stop)
06 (no range, or all)
129 (response) 00 (start-stop)
1 0 Binary Input – Any Variation 1 (read)
00, 01 (start-stop)
06 (no range, or all)
To Next Page
