Rockwell Automation Publication 2080-UM002N-EN-E - November 2022 15

Chapter 1

Hardware Overview

This chapter provides an overview of the Micro830®, Micro850®, and Micro870® controller

hardware features. It has the following topics:

Topic Page

Hardware Features 16

Micro830 Controllers 16

Micro850 Controllers 17

Micro870 Controllers 19

Programming Cables 21

Embedded Serial Port Cables 21

Embedded Ethernet Support 22
