34
Chapter 3. About the D-FIELD
Changing the volume of the parts (X-FADER)
The volume or pan of two parts can be controlled simultaneously.
➔ Changing the D-FIELD settings (p. 22)
As an alternate way to select the part that will be controlled, you can hold down [X-FADER] and press a part button while making
X or Y settings. (At this time, the selected part button will blink.)
When TYPE is “LEVEL,” it is not possible for the volume to become louder than the volume setting of the pattern.
Making the sound change over time (ASSIGN 2: ENVELOPE)
fig.ENV—
You can control the time-variant change in pitch, tone, and volume of the current part.
➔ Changing the D-FIELD settings (p. 22)
Display Explanation Setting
TYPE Specify whether you will control volume or pan. LEV (LEVEL), PAN
X Select the part that will be affected when you move your
finger to left or right.
P-r, P-1–P-7
* It is not possible to select
the same part for both X
and Y.
Y Select the part that will be affected when you move your
finger upward or downward.
Display Explanation Setting
TYPE none none none
X Select the parameter that will be
affected when you move your
finger to left or right.
OFF,
PITCH DEPTH, PITCH ATTACK TIME, PITCH DECAY TIME,
PITCH SUSTAIN LEVEL, PITCH RELEASE TIME, FILTER DEPTH,
FILTER ATTACK TIME, FILTER DECAY TIME,
FILTER SUSTAIN LEVEL, FILTER RELEASE TIME,
AMP ATTACK TIME, AMP DECAY TIME, AMP SUSTAIN LEVEL,
AMP RELEASE TIME
* It is not possible to select the same parameter for both X and Y.
Y Select the parameter that will be
affected when you move your
finger upward or downward.
About the envelope
These parameters specify how the pitch, filter, or amp will change over time. As shown in
the diagram below, this allows you to specify how change will occur from the beginning to
the end of the sound.
fig.Envelope
+
0
Attack
Sustain
Decay Release
Pitch
Filter (Cutoff Frequency)
Level
Time
Note On Note Off
To Next Page
