MIDI Implementation
Model: D2 (groovebox)
Date: Mar. 12, 2001
Version: 1.00
Symbol Description Range
n MIDI Channel 0H–6H,9H (ch.1–ch.7,ch.10)
vv Control value 00H–7FH (0–127)
kk Note Number 00H–7FH (0–127)
xx ON/OFF 00H–3FH (0–63:OFF), 40H–7FH (64–127:ON)
1. Data reception (sound source section)
■Channel voice messages
●Note Off
status 2nd byte 3rd byte
8nH kkH vvH
9nH kkH 00H
vv=Note Off velocity: 00H - 7FH (0 - 127)
●Note On
status 2nd byte 3rd byte
9nH kkH vvH
vv=Note On velocity: 01H - 7FH (1 - 127)
●Polyphonic Aftertouch
status 2nd byte 3rd byte
AnH kkH vvH
vv=Polyphonic Aftertouch: 00 00H - 7FH (0 - 127)
●Control Change
* Not received when the Rx Switch parameter is OFF.
❍Bank Select (Controller number 0,32)
status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
mm,ll=Bank number: 00 00H–7F 7FH (bank.1–bank.16384)
* Not received when the Rx Program Change Switch or Rx Bank Select Switch parameter
is OFF.
* The Patches corresponding to each Bank Select are as follows.
Bank Select | Program No | Group Patch No.
MSB | LSB | |
——————+—————+————————————+————————————————————————————————————————
81 | 0 | 001 - 128 | Preset A 001 - 128
81 | 1 | 001 - 128 | Preset B 001 - 128
81 | 2 | 001 - 128 | Preset C 001 - 128
81 | 3 | 001 - 128 | Preset D 001 - 128
84 | 0 | 001 - 088 | Preset E 001 - 088
85 | 0 | 001 - 128 | User 001 - 128
85 | 1 | 001 - 128 | User 129 - 256
* The Rhythm set corresponding to each Bank Select are as follows.
Bank Select | Program No | Group Patch No.
MSB | LSB | |
——————+—————+————————————+————————————————————————————————————————
81 | 0 | 1 - 26 | Preset A 01 - 26
84 | 0 | 1 - 4 | Preset B 01 - 04
85 | 0 | 1 - 20 | User 01 - 20
❍Modulation (Controller number 1)
status 2nd byte 3rd byte
BnH 01H vvH
* The effect will apply according to the Modulation Control setting.
❍Data Entry (Controller number 6,38)
status 2nd byte 3rd byte
BnH 06H mmH
BnH 26H llH
mm,ll= the value of the parameter specified by RPNmm=MSB, ll=LSB
❍Expression (Controller number 11)
status 2nd byte 3rd byte
BnH 0BH vvH
* Expression messages are used to adjust the volume of each part.
❍Hold 1 (Controller number 64)
status 2nd byte 3rd byte
BnH 40H xxH
❍Sostenuto (Controller number 66)
status 2nd byte 3rd byte
BnH 42H xxH
❍Soft (Controller number 67)
status 2nd byte 3rd byte
BnH 43H xxH
❍Hold 2 (Controller number 69)
status 2nd byte 3rd byte
BnH 45H xxH
❍Portamento Control (Controller number 84)
status 2nd byte 3rd byte
BnH 54H kkH
* A Note On message received immediately after a Portamento control will be sounded
with the pitch changing smoothly from the source note number. If a voice is already
sounding at the same note number as the source note number, that voice will change
pitch to the pitch of the newly received Note On, and continue sounding (i.e., will be
played legato).
* The speed of the pitch change caused by Portamento is determined by the Portamento
Time parameter.
❍RPN MSB/LSB (Controller number 100,101)
status 2nd byte 3rd byte
BnH 65H mmH
BnH 64H llH
mm=MSB of the parameter number specified by RPN
ll=LSB of the parameter number specified by RPN
<< RPN >>
Control Changes include RPN (Registered Parameter Numbers), which are extended
parameters whose function is defined in the MIDI specification.
When using RPNs, first the RPN (Controller numbers 100 and 101; they can be sent in any
order) is transmitted to specify the parameter you wish to control. Then, Data Entry
messages (Controller numbers 6 and 38) are used to set the value of the specified parameter.
Once a RPN parameter has been specified, all further Data Entry messages on that channel
are considered to apply to that specified parameter. In order to prevent accidents, when the
desired setting has been made for the parameter, it is recommended that RPN be set to Null.
This device receives the following RPNs.
RPN Data entry
MSB LSB MSB LSB Notes
00H 00H mmH — Pitch Bend Sensitivity
mm : 00H–0CH (0–12 semitones)
ll : ignored (processed as 00H)
Up to 1 octave can be specified in semitone steps.
*The Bend Range up parameter, Bend Range Down parameter will
also be changed.
*Not received by the Part R.
00H 01H mmH llH Master Fine Tuning
mm, ll: 20 00H–40 00H–60 00H ( -4096 x 100 / 8192–0–+4096 x 100 /
8192 cent )
*The Fine Tune parameter of each Part will change.
00H 02H mmH — Master Coarse Tuning
mm : 10H–40H–70H (-48–0–+48 semitones)
ll : ignored (processed as 00H)
*The Key Shift parameter of each Part will change.
7FH 7FH — — RPN null
RPN will be set as “unspecified”. Once this setting has been made,
subsequent Data Entry messages will be ignored. (It is not necessary to
transmit Data Entry for RPN Null settings.) Parameter values that
were previously set will not change.
mm, ll: ignored
*
For the functions of other controller numbers, refer to
“Table of Transmitted Data” (p. 76).
