Repeat Relay Mode Of Operation
The repeat relays can be configured to operate as: -
Input Follower
The relay will activate when an alarm occurs and automatically return to normal when the alarm
returns to the normal state.
Logic Follower
The individual relay will activate when an alarm occurs and only return to normal when the alarm has
returned to the normal state and the logic has been reset.
FUNCTION ALARM CARD CHANNEL SPR CARD
1 - 2 3 - 4 1 - 2
Input Follower SW4.S1 = ON SW6.S1 = ON Automatic
Logic Follower SW4.S1 = OFF SW6.S1 = OFF
Table 12
Operation of Repeat Relays During Test
Repeat Relays configured to Logic Follower Mode can be set so that they will not operate when the
System Test Pushbutton is pressed.
FUNCTION ALARM CARD CHANNEL SPR CARD
1 - 2 3 - 4 1 - 2
Disable SW4.S6 = ON SW6.S6 = ON SW5.S4 = ON
Enable SW4.S6 = OFF SW6.S6 = OFF SW5.S4 = OFF
Table 13
System Test
System test simulates a full alarm condition on all channels therefore the associated LED’s will flash
and the audible alarm will sound. The appropriate pushbuttons, Ack, Mute & Reset will need to be
pressed, depending on the selected alarm sequence, to return the alarms to their normal off state.
Disable Horn On System Test Option “DHT” (Model Suffix Code M1)
As an option it is possible to provide the UC625 Unit so that the horn outputs are disabled during
system test if required. Option DHT must be specified at time of order placement if this feature is
required.
LED Indication
The Series UC625 Alarm Annunciator is supplied with 8mm super bright LED’s mounted in the left
hand corner of the associated window. The LED is normally supplied in red but other colours are
available on request.
