Card Switch Settings Required To Set Alarm Sequences
Switch Suffix Number
Sequence
Card
Channels
Switch
-S1
-S2
-S3
-S4
-S5
-S6
-S7
Page
ISA-M
Manual Reset
Alarm
1 - 2 SW3 ON *** ON *** OFF OFF OFF OFF OFF
18
3 - 4 SW5 ON *** ON *** OFF OFF OFF OFF OFF
SPR 1 - 2
SPR Card is supplied in Sequence ISA-M ONLY
ISA-A
Automatic Reset
Alarm
1 - 2 SW3 ON *** ON *** OFF OFF OFF ON OFF
3 - 4
SW5
ON ***
ON ***
OFF
OFF
OFF
ON
OFF
ISA-A-4
Non Lock In
Alarm
1 - 2 SW3 ON *** ON *** OFF OFF ON ON OFF
19
3 - 4 SW5 ON *** ON *** OFF OFF ON ON OFF
ISA-R
Ringback
Alarm
1 - 2 SW3 ON ON OFF ON OFF OFF OFF
3 - 4
SW5
ON
ON
OFF
ON
OFF
OFF
OFF
ISA A-5-6
Status Only
Alarm
1 –2 SW3 ON OFF OFF OFF ON ON OFF
3 - 4 SW5 ON OFF OFF OFF ON ON OFF
*** The above Sequences can be set to be FAST or SLOW FLASH using the following
Flash Rate Card Channels Switch -S1 -S2
Fast Flash
Alarm
1 - 2
SW3
ON
ON
Slow Flash 1 - 2 SW3 OFF OFF
Fast Flash 3 - 4 SW5 ON ON
Slow Flash 3 - 4 SW5 OFF OFF
First-Up Alarm Sequences
ISA-F1A Alarm
1 - 2 SW3 ON OFF OFF OFF OFF ON ON
20
3 - 4 SW5 ON OFF OFF OFF OFF ON ON
ISA-F2M-1 Alarm
1 - 2
SW3
OFF
ON
OFF
OFF
OFF
OFF
ON
3 - 4 SW5 OFF ON OFF OFF OFF OFF ON
Table 30 Switch Settings Per Alarm Sequence
