RTK UC625 series User Manual

28
Signal Supply
Monitor Relays
On systems supplied after 1
st
January 2008 a signal supply monitor
relay is provided to indicate loss of the supply
Pushbuttons
Pushbuttons
System Test Mute
Acknowledge Reset
General
Supply Voltage
Supply 1 - 88-265VAC or 88-360VDC
Supply 2 - 88-265VAC or 88-360VDC
Option Supply 2 - 24VDC
(19-31VAC/DC)
Supply Current
Alarm Card 2mA Each Quiescent
Alarm Card 140mA Each Full Load
Pushbutton Module Each 100mA
Fuses
Signal Supply Fuse 125mA – Mounted on Cabinet Rear
24VDC Aux Supply Fuse 1A – Mounted on SPR Card
Terminals
Rising clamp type terminals. Maximum cable size 2.5mm
²
EMC Compliance
Immunity to BS EN50082-2:1995
Emissions to BS EN50081-2:1994
LVD Compliance BS EN 61010:1:1993
Operating Temp
-10
o
C to 60
o
C
Storage Temp
-20
o
C to 80
o
C
Humidity 0-95% RH, non condensing
Protection IP51
Typical Burden on 125VDC Power Input
No of Ways
Current in mA
8
60
12
72
16
85
20
96
24
108
28
120
32
140
36
146
40
160
