16-5 NuSX CONNECTIONS
The NuSX GAme Bd has various connections which are required by this game and therefore need to be connected
for the game to function correctly.
Any other connection made to the NuSX which are not highlighted in this section shoul d not be made.
DO NOT connects phone chargers or any other auxillary electronic item into the unused USB posts. Connection
items such as chargers will cause an over current power demand which can result in malfunction or even fire
hazzard.
PWR INPUT
Sw1
Test Switch
Sw2
Service Switch
JVS
USB to JVS I/O Bd
Audio Out
3.5mm Jack to Audio Amp
COM 2
LED Controller
DVI
Video Output
USB
Security Key Chip
