BASIC OPERATION
CHAPTER 1 | FCM2041-U3 OPERATOR INTERFACE MANUAL
1-7
NORMAL MODE Normal mode is the absence of any off-normal conditions.
The screen displays SYSTEM STATUS: NORMAL with the time and date. If a custom
message has been programmed using the Zeus tool (refer to Zeus Quick Start Guide,
P/N 315-033875), the node custom message also displays in this mode. See Figure 1-5.
CUSTOM MESSAGE
Cerberus PRO Modular System
10:26:12 07/12/ 02
SYSTEM STATUS: NORMAL
.
Figure 1-4
Normal Mode Display
The POWER LED glows steady green in Normal mode when the System has AC
power. The ALARM, AUDIBLE ON, AUDIBLE SILENCE, SUPERVISORY, TROUBLE,
SECURITY, and PARTIAL SYSTEM DISABLE LEDs are off and the internal audible is off.
Menu Press the Menu button (see
q on page 1-2) to display a menu of all OI options. See
Figure 1-5. The currently available options are described below.
Alert
Report
Maint
10:53
Category text information
Logout
Diagnostics
Lamp Test
Alt. Language*
Press any lit green arrow key to continue.
Press “?” for more help information.
ALERT: Firefighter’s Mode, view events.
REPORT: View/Print event and system info.
MAINT: Control devices and inputs/outputs.
FUNCTION KEYS: Execute logic commands.
LOGOUT: Leave password protected area.
DIAGNOSTICS: For factory use only.
LAMP TEST: 30 second PMI LED test.
Function Keys
Menu
FireFighter@1
Figure 1-5
Menu Screen
ALERT MODE When an event occurs in the system, the display enters the Alert or Firefighter’s
mode automatically. The events are displayed in priority order, the local audible
sounds and the appropriate LED blinks. If the event caused notification appliances to
sound, the Audibles On indicator lights. At the bottom of the screen an Acknowledge
soft key is displayed. Pressing this key acknowledges the event and silences the local
audible. A Silence Audibles soft key is displayed at the bottom of the screen.
* The alternate language is only visible/present if the Zeus
programming tool has been set for two languages--a base
language and an alternate language.
To Next Page
