BASIC OPERATION
FCM2041-U3 OPERATOR INTERFACE MANUAL | CHAPTER 1
1-12
Supervisory When a supervisory is detected, the yellow Supervisory LED blinks, the System’s
internal audible pulses, and the event(s) display on the screen with a blinking exclama-
tion mark (!). This event listing displays the Event Custom Message, the Time of the
event occurrence and the Supervisory Event Category (i.e., Security, Sprinkler, etc.).
In addition, the System responds to supervisories with other output functions (as
programmed in the Zeus tool).
An Acknowledge Supervisory soft key displays in the bottom left corner of the
screen. Press this key to acknowledge each supervisory and to silence the local
audible. The blinking exclamation point (!) then changes to a check mark (9). See
Figure 1-6.
Security When a security is detected, the yellow Security LED blinks, the System’s internal
audible pulses, and the event(s) display on the screen with a blinking exclamation
mark (!). This event listing displays the Event Custom Message, the Time of the event
occurrence and the Security Event Category (i.e., Door, Monitor Point, etc.).
In addition, the System responds to securities with other output functions (as
programmed in the Zeus tool).
An Acknowledge Security soft key displays in the bottom left corner of the screen.
Press this key to acknowledge each security and to silence the local audible. The
blinking exclamation point (!) then changes to a check mark (9). See Figure 1-6.
Trouble When a trouble is detected, the yellow Trouble LED blinks, the System’s internal
audible pulses, and the event(s) display on the screen with a blinking exclamation
mark (!). This event listing displays the Event Custom Message, the Time of the event
occurrence and the Trouble Event Category (refer to the Trouble Event: Category
Cross Reference Table that follows).
ECNEREFER-SSORCYROGETAC:TNEVEELBUORT
yrogetaCeciveDlacisyhP
ECIVED ro,poolCLMroMPV,CLDX,CLDanoecivedtupnidesivrepusynA
-TPF,11-PF,secivedIRTH,
11-TPFH,11-PFH,.e.i-troperelbuorttiucric/enoz
.stiucricdesivrepusyllaudividni61-MIS,MCO,SMH,secivedIRT
,11
ENOZ 5-DAP,senoz6B1-/1-MZC,senozMZH,senozMAZ,senozCAZ,senozCIZ
senoz
ELUDOM ,MAZ,CIZ,MPV,CLM,CLDX,CLD,
IMP,.e.i-elbuorteludomdesivrepusynA
.CIN,XSP,CSP
METSYS cificepsaotdetniopniptoneratahtseruliaf/elbuortd
etaler-metsySynA
.ecivedroenoz,eludom
KROWTENTENH/TENX
.elbatcelesdleiftoneradnayrotcafehtybdenifed-erper
aseirogetacesehtfollA:ETON
In addition, the System responds to troubles with other output functions (as pro-
grammed in the Zeus tool). An Acknowledge Trouble soft key displays in the bottom
left corner of the screen. Press this key to acknowledge each trouble and to silence
the local audible. The blinking exclamation point (!) then changes to a check mark (9).
See Figure 1-6.
