BASIC OPERATION
FCM2041-U3 OPERATOR INTERFACE MANUAL | CHAPTER 1
1-2
?
ESC
+
More
Info
MENU
CPU FAIL
PARTIAL
SYSTEM
DISABLED
SILENCED
ON
AUDIBLES
TROUBLE
SUPERVISORY
ALARM
POWER
1
3
Menu
Scroll UP through
the list of events
When lit, provides
more information on
the highlighted event
Go back to previous scree
n
Scroll DOWN through
the list of events
Context sensitive help
MNS1
000
FIRE ALARM LIST
Device custom message
10:53
!
Device custom message
Event Category
Event Category
11:00 (Currently not used)
Device custom message
10:57
(Currently not used)




Device custom message
Event Category
11:03
(Currently not used)
Device custom message
Event Category
Acknowledge
Alarms
Silence
Audibles
Unsilence
Audibles
Re se t
System
11: 06 (Currently not used)
(Currently not used)
4
2
7
Move to the right-most tab
M
ove to the left-most tab
Move one tab right
Move one tab left
Node X in Control
ALM
001
MNS2
000
EMG
001
MNST
000
OTH
000
BIDG
000
SUP
001
TBL
001
F
C
M2041-U3
5
6
8
2
Figure 1-1
FCM2041-U3 Operator Interface
Interface Overview
n LEDs blink when an event is reported and unacknowledged (ALARM: red,
SUPERVISORY: yellow, SECURITY: yellow, TROUBLE: yellow).
The LEDs glow steady if all events in the class/queue are acknowledged. An
internal audible alarm sounds steady when there is an unacknowledged fire alarm.
It pulses if all alarms are acknowledged, but there is at least one security,
supervisory, or trouble condition.
o Along the top and bottom of the LCD are rows of four soft keys. The function of
these keys depends on the screen that is currently displayed. Each of the soft
keys has a green LED that is used to guide the operator to the available actions.
For FCM2041-U3 in ‘expanded’ queue mode, the soft keys at the top of the LCD
