CHAPTER 2 | FCM2041-U3 OPERATOR INTERFACE MANUAL
REPORT MODE
2-7
Menu:Report:Status:Sensitivity
PHY:FireFinder@1, DLC@1
Sensitivity Report
AT: FireFinder@1, DLC@1
Cancel Settings View
SETTINGS:
Node: None
Module: None
SubModule: None
Device: Smoke
Figure 2-7
Sensitivity Report Settings Status Screen
Press the View soft key to display the list of Detector Sensitivities. As the system
reads all device sensitivities for the module/loop or device it might display the
message Acquiring Data. When the data is received, it displays on the OI screen. See
Figure 2-8.
If the list of information exceeds what can be displayed on the screen, a scroll bar
appears with an arrow on the bottom indicating the list continues. To view the
remaining items on the list, press the DOWN arrow button. If the down arrow button
remains depressed, the list scrolls progressively faster until it reaches ten items at a
time. To highlight the first item in a report list, press More Info/+; to highlight the last
item in a report list, press
(FCM2041-U3).
:1-3 HFP11 10.09
:1-4 HFP11 10.09
:1-5 HFP11 10.09
:1-6 HFP11 10.09
:1-7 HFP11 10.09
:1-8 HFP11 10.09
:1-9 HFP11 10.09
:1-10 HFP11 10.09
:1-11 HFP11 Acquiring Data
:1-12 HFP11 Acquiring Data
10:53
Category text information
Menu:Report:Status:Sensitivity:View
PHY:FireFinder@1, DLC@1
Cancel Print
Sensitivity Report
Address Device Sensitivity(%/Meter) 25%
:1-3 HFP11 10.09
GoTo
Select
:1-3 FP11 1.9
:1-4 FP11 1.9
:1-5 FP11 1.9
:1-6 FP11 1.9
:1-7 FP11 1.9
:1-8 FP11 1.9
:1-9 FP11 1.9
:1-10 FP11 1.9
:1-11 FP11 Acquiring Data
:1-12 FP11 Acquiring Data
10:53
Category text information
Menu:Report:Status:Sensitivity:View
PHY:FireFinder@1, MLC@1
Cancel Print
Sensitivity Report
Address Device Sensitivity(%/Foot) 25%
GoTo
:1-3 FP11 1.9
Figure 2-8b
Sensitivity Report Screen (%/M, DLC)
Figure 2-8c
Sensitivity Report Screen (%/Ft, MLC)
Figure 2-8
Sensitivity Report Screen (%/Ft, DLC)
10:53
Category text information
:1-3 HFP11 1.9
:1-4 HFP11 1.9
:1-5 HFP11 1.9
:1-6 HFP11 1.9
:1-7 HFP11 1.9
:1-8 HFP11 1.9
:1-9 HFP11 1.9
:1-10 HFP11 1.9
:1-11 HFP11 Acquiring Data
:1-12 HFP11 Acquiring Data
Menu:Report:Status:Sensitivity:View
PHY:FireFinder@1, DLC@1
Cancel Print
Sensitivity Report
Address Device Sensitivity(%/Foot) 25%
:1-3 HFP11 1.9
GoTo
Select
