FCM2041-U3 OPERATOR INTERFACE MANUAL | CHAPTER 3
MAINTENANCE MODE3-10
Change ASD can only be performed at the device level (Physical view) and Bypass
ASD can only be performed at the module (DLC, XDLC, or MLC) level. These opera-
tions will appear grayed out on the OI when the system is set at any other level.
Press the Control soft key. [If the appropriate level password has not been previously
entered or if it has timed out, the Enter Password screen displays. (See page 3-1.)]
The Control menu displays. Touch the desired operation to either bypass, enable or
change the ASD setting.
Bypass ASD Touch the box labeled Bypass ASD and a screen displays showing the number of
devices that will be bypassed. See Figure 3-16.
Bypass CO can be done only at device level. Touch the box labeled Bypass CO on the
screen. This will set sensitivity level for individual CO detectors to 40ppm. Pressing
Enable CO will set CO sensitivity back to 60ppm.
At this point, the ASD setting has not been bypassed.
10:53
Category text information
Menu:Maint:Control:BypassASD
PHY:FireFinder@1, DLC@3
Cancel
BYPASS ASD
AT: FireFinder@1, DLC@3
# ASD Devices: 63
Execute
Figure 3-16
Bypass ASD Status Screen
Press the Execute soft key to bypass the ASD setting.
Enable ASD To Enable ASD, follow the steps above in Bypass ASD, selecting the Enable setting
instead of the Bypass setting.
Change ASD To Change the ASD settings, you must first navigate to the device level using the
More Info/+ button. Then follow the steps above in Disable ASD, selecting the
Change ASD setting instead of the Disable setting. Press the Settings soft key to
display all the possible ASD settings. The current ASD setting is highlighted. See
Figure 3-17.
Cancel
OK
Menu:Maint:Control:ChangeASD:Settings
PHY:FireFinder@1, DLC@1
Disable
Office
Warehouse
Lobby
Computer room
Dormitory
Healthcare
Garage
Utility room
Precious storage
Hostile Env
Duct
Figure 3-17
Change ASD Setting
