Remote-SAT User's Guide
P R E L I M I N A R Y
MC35_SAT_01_V01.01a - Preliminary Page 32 of 64 15.11.2001
1.4.10 AT^SSTGI Remote-SAT Get Information – Display Text (33)
Write command
AT^SSTGI=33
This command is to be used upon receiving an unsolicited result code
^SSTN:33.
The TA is being passed a message to display to the user, which can have
different display characteristics.
Text and an Icon Identifier can be passed to the TA to display to the user.
Response
^SSTGI: <cmdType>, <commandDetails>, <text>, <immediateResponse>,
<iconQualifier>, <iconId> <CR> <LF>
Parameters
<cmdType> 33 – Proactive command ID, see Table 1
<commandDetails> Unsigned Integer, range 0 – 255, used as a bitfield.
bit 1: 0 = normal priority
1 = high priority
bits 2-7: = RFU
bit 8: 0 = clear message after a delay
1 = wait for user to clear message
<text> String to be displayed (up to 240 bytes)
<immediateResponse> Indicates when to send TERMINAL RESPONSE
0 = send TERMINAL RESPONSE when text
clears from screen
1 = TERMINAL RESPONSE sent immediately
<iconQualifier> Unsigned Integer, range 0 – 255, used as a bitfield.
bit 1: 0 = icon is self explanatory and replaces text
1 = icon is not self-explanatory and shall be
displayed with the text
Determined value only if associated icon id is
not 0 (an icon exists).
bits 2-8: = RFU
<iconId> 0-255, 0: no icon
Reference
Siemens
