Remote-SAT User's Guide
P R E L I M I N A R Y
MC35_SAT_01_V01.01a - Preliminary Page 34 of 64 15.11.2001
1.4.12 AT^SSTGI Remote-SAT Get Information – Get Input (35)
Write command
AT^SSTGI=35
This command is to be used upon receiving an unsolicited result code
^SSTN:35.
The TA is asked to prompt the user for an input, of a specified length and type,
e.g. digits only. Help can be requested by the user, if available.
Text and an Icon Identifier can be passed to the TA to display to the user.
Response
^SSTGI: <cmdType>, <commandDetails>, <text>, <responseMin>,
<responseMax>, [<defaultText>], <iconQualifier>, <iconId> <CR> <LF>
Parameters
<cmdType> 35 – Proactive command ID, see Table 1
<commandDetails> Unsigned Integer, range 0 – 255, used as a bitfield.
bit 1: 0 = digits (0-9, *, #, and +) only
1 = alphabet set
bit 2: 0 = SMS default alphabet (GSM character set)
1 = UCS2 alphabet
bit 3: 0 = ME may echo user input on the display
1 = user input shall not be revealed in any way
(see note)
bit 4: 0 = user input to be in unpacked format
1 = user input to be in SMS packed format
bits 5 to 7: RFU
bit 8: 0 = no help information available
1 = help information available
<text> String as prompt for text
<responseMin> minimum length of user input (0 – 255)
<responseMax> maximum length of user input (0 – 255)
<defaultText> String supplied as default response text
<iconQualifier> Unsigned Integer, range 0 – 255, used as a bitfield.
bit 1: 0 = icon is self explanatory and replaces text
1 = icon is not self-explanatory and shall be
displayed with the text
Determined value only if associated icon id is
not 0 (an icon exists).
bits 2-8: = RFU
<iconId> 0-255, 0: no icon
Reference
Siemens
Note
Hidden entry mode (GSM 11.14) is only available when using digit input. In
hidden entry mode only characters ‘0’-‘9’, ‘*’ and ‘#‘ are allowed.
