Siemens RDF800KN Series User Manual

12 / 94
Siemens RDF800KN.., RDF800KN/VB, RDD810KN/NF Basic documentation CE1P3174en
Smart Infrastructure 2020-02-21
2.6 Equipment combinations
Description
Product no.
Data
S
heet
Cable temperature sensor or
changeover sensor, cable length
2.5 m
NTC (3 kW at 25 °C)
QAH11.1 1840
Room temperature sensor
NTC (3 kW at 25 °C)
QAA32 1747
Cable temperature sensor,
cable length 4 m
NTC (3 kW at 25 °C)
QAP1030/UFH 1854
Condensation monitor
QXA2100/
QXA2101
A6V10741072
Electromotoric On/Off actuator SFA21.. 4863
Electromotoric On/Off valve and
actuator (only available in AP,
UAE, SA and IN)
MVI../MXI.. A6V11251892
Zone valve actuator (only available
in AP, UAE, SA and IN)
SUA.. 4832
Thermal actuator (for radiator
valve)
STA23.. 4884
Thermal actuator
(for small valves 2.5 mm)
STP23.. 4884
Electrical actuator, 3-position
(for radiator valve)
SSA31.. 4893
Electrical actuator, 3-position
(for small valve 2.5 mm)
SSP31.. 4864
Electrical actuator, 3-position
(for small valve 5.5 mm)
SSB31.. 4891
Electrical actuator, 3-position
(for 2- and 3-port valves/V..P45)
SSC31.. 4895
Electrical actuator, 3-position
(for small valve 5.5 mm)
SSD31.. 4861
Electromotoric actuator, 3-position
(for small valves 5.5 mm)
SQS35.. 4573
Notes:
For the maximal number of actuators operating in parallel, refer to information in the
Data Sheets of the selected actuators and the following information, depending on
which value is lower:
· Parallel operation of max 6 SS.. actuators (3-position) is possible.
· Parallel operation of max 10 On/Off actuators is possible.
·
Parallel operation of SQS35 is not possible.
On/Off actuators
3-position actuators
