Siemens RDF800KN.., RDF800KN/VB, RDD810KN/NF Basic documentation CE1P3174en
Smart Infrastructure 2020-02-21
3.14.4 Expert level parameters with diagnostics and test
Parameter
Name Factory setting Range
RDD810KN/NF RDF800KN.., RDF800KN/VB Dependencies
Expert level
P30
Heat P-band Xp/switching
differential
2 K 0.5…6 K
ü ü
P31
Cool P-band Xp/switching
differential
1 K 0.5…6 K x
ü
P33 Dead zone Comfort mode 2 K 0.5…5 K x
ü
Appl.
*)
P34 Setpoint differential 2 K 0.5…5 K
x ü
Appl.
*)
P35
Integral action time Tn
45 min 0...120 min x
ü
P46
P36
H/C changeover switching
point cooling
16 °C 10…25 °C x
ü
P38,
P40
P37
H/C changeover switching
point heating
28 °C 27…40 °C x
ü
P38,
P40
P38 Input X1 3 = window contact
0 = --- (no function)
1 = room temp ext. sensor/
return air temp (AI)
2 = H/C changeover (AI/DI)
3 = window contact (DI)
4 = dew point sensor (DI)
5 = enable electric heater (DI)
6 = fault input (DI)
7 = monitor input (Digital)
8 = monitor input (Temp)
9:= supply air sensor (AI)
10 = presence detector (DI)
0,
1,
3,
6,
7,
8,
10
on
ly
ü
P40
P39 Normal position input X1 0 (NO)
0 = normally open/open
1 = normally closed/close
ü ü
P38
P40 Input X2 1 = ext. sensor
0 = --- (no function)
1 = room temp ext. sensor/
return air temp (AI)
2 = H/C changeover (AI/DI)
3 = window contact (DI)
4 = dew point sensor (DI)
5 = enable electric heater (DI)
6 = fault input (DI)
7 = monitor input (Digital)
8 = monitor input (Temp)
9:= supply air sensor (AI)
10 = presence detector (DI)
0,
1,
3,
6,
7,
8,
10
on
ly
ü
P38
P41 Normal position input X2 0 (NO)
0 = normally open/open
1 = normally closed/close
ü ü
P40
P44 Actuator running time Y1/Y2 150 s 20…300 s x
ü
P46
P45
Power of electric heater on
Y2 (for adaptive temperature
compensation
0.0 kW 0.0...1.2 kW
x
ü
P46 Output Y1/Y2 On/Off (1)
0 = 3-position
1 = On/Off
x
ü
Appl.
P48
ON time minimum 2-pos
output
1 min. 1...20 min
ü ü
P46
P49
OFF time minimum 2-pos
output
1 min. 1...20 min
ü ü
P50 Purge time OFF OFF: Not active
1…5 min: Active with selected
duration
x
ü
P38,
P51 Flow temp limit floor heating OFF OFF, 10...50 °C
ü ü
P38,
P40
P52 Fan control 1
0 = disabled
1 = enabled
2 = heating only
3 = cooling only
x
ü
