Description
3.3 System description of SCALANCE X-400
SCALANCE X-400
Operating Instructions, 06/2015, C79000-G8976-C186-12
33
Transmission range
The maximum transmission range (segment length) is 120 km for single mode FOC.
Connectors
SC duplex female connectors are used.
3.3.3
Compatibility of SCALANCE X-400
Compatibility list
The following products and devices are compatible with IE Switches X-400:
● End devices
All SIMATIC NET products with a TP port can be connected to the ports of the
IE Switches X-400.
● Network components in linear or star structure
ESM/OSM
OMC (TP cable max. 6 m long)
SCALANCE X005
SCALANCE X-100
SCALANCE X-100 medium converter
SCALANCE X-200
SCALANCE X-200IRT
SCALANCE S-600
SCALANCE W-700
● Network components in a ring structure with IE-Switches X-400 as RM
ESM/OSM
SCALANCE X-200
SCALANCE X-200IRT
● Redundant coupling of networks.
– In the network segment with the master-slave pair to be configured:
SCALANCE X-400
– In the network segment to be coupled:
ESM/OSM
SCALANCE X-200
SCALANCE X-200IRT
SCALANCE X-400
Note
All compatibility information assumes the correct use of the TP and FOC cables.
