Description
3.4 Description of the product
SCALANCE X-400
60 Operating Instructions, 06/2015, C79000-G8976-C186-12
Properties
The media module provides two ports for connecting the single mode FOC. The signals are
transmitted with a DFB laser diode at a wavelength of 1550 nm. Both ports of the module
can be configured as ring ports. The max. line length is 70 km.
Connector
SC duplex female connectors are used.
3.4.4.9
Gigabit media module MM492-2ELH (1000Base-LX)
Introduction
● SCALANCE X414-3E
The MM492-2ELH gigabit media module can be inserted as an option in slot 5.
● SCALANCE X408-2
The MM492-2ELH gigabit media module can be inserted as an option in slots 5 and 6.
Mixed operation with the gigabit Ethernet media modules MM492-2, MM492-2LD;
MM492-2LH and MM492-2LH+ and the Fast Ethernet media modules MM491-2,
MM491-2LD and MM491-2LH+ is possible.
Note
This media module can be used as of product version 05 of the SCALANCE X414
-3.
This media module is recognized by the SCALANCE X414
-3E and SCALANCE X408-2
only as of firmware version 3.0
Properties
The media module provides two ports for connecting the single mode FOC. The signals are
transmitted with a DFB laser diode at a wavelength of 1550 nm. Both ports of the module
can be configured as ring ports. The max. line length is 120 km.
Connector
SC duplex female connectors are used.
