Siemens SCALANCE X-400 User Manual

Description
3.4 Description of the product
SCALANCE X-400
Operating Instructions, 06/2015, C79000-G8976-C186-12
65
Covers
Four CV490 2x100 covers are supplied with the twisted media module extender EM496-4.
The media module plug connectors are also protected from damage by protective caps.
Figure 3-31 Media module extender EM496-4 with media module MM491-2 in slot 12 and with cover
3.4.6
C-PLUG (configuration plug)
Application
The C-PLUG is an exchangeable medium for storage of the configuration data of the
modular switch and ships with the product. This means that the configuration data remains
available if the basic device is replaced.
Note
The C
-PLUG must only be removed or inserted when the power supply to the device is
turned off.

Siemens SCALANCE X-400 Specifications

General

Brand	Siemens
Model	SCALANCE X-400
Category	Switch
Language	English
