Getting Started - ET 200S-IM 151/CPU Interface Module
A5E00058783-01
8-9
6WHS7HVW5XQ
6WDJH 3URFHGXUH 5HVXOW
1
In SIMATIC Manager, click %ORFNVin the left-hand
part of the dialog box.
%ORFNVis highlighted.
2
Right-click the right-hand part of the window, and
insert an empty organization block with the name
2% into the block container.
This block ensures that the S7-300 CPU will start
even if the IM157/CPU is still indicating an I/O error.
Generate OB86 in the same way.
1RWH
OB82 and OB86 are not important until DP slave
operation.
The blocks OB82 and OB86 appear
next to block OB1.
3 Select the block container in the left-hand part of the
window again.
From the 3/& menu, choose the 'RZQORDG
command to transfer the program and the hardware
configuration to the CPU.
Click <HV in all the dialog boxes that appear.
The program and configuration are
downloaded from the programming
device to the CPU.
4
Switch the CPU mode selector to 5813
The 6723LED goes out. The 581
LED starts flashing and then comes on
continuously.
5 Operate the two switches alternately. The LEDs of the inputs 1.0 and 1.2
light up alternately.
The LED of output 2.0 does not light
up.
6 Operate the two switches simultaneously.
The LEDs of inputs 1.0 and 1.2 (and
LEDs of the DI) light up together.
Because the two switches are ANDed
in the program (series connection) and
assigned to the output 2.0, the LED of
output 2.0 (LED of the DO) lights up.
This would switch on a connected
actuator or indicator.
7
Switch the CPU mode selector to 6723, and switch
off the PS of the IM 151/CPU.
All the LEDs go out.
