Functions of the IM 151/CPU
5-2
ET 200S Interface Module IM 151/CPU
A5E00058783-01
5.1 Data for the PROFIBUS-DP
DDB (Device Database) File
A DDB file contains all the slave-specific properties. The structure of the DDB file
is defined in IEC 61158/EN 50170, Volume 2, PROFIBUS.
You only need the DDB file if:
 You are using the ET 200S with a DP master from the SIMATIC S5 range
(configuration with COM PROFIBUS).
 You are using the ET 200S with a non-SIMATIC DP master (configuration with a
non-Siemens tool).
You can download the DDB file from the Internet. You will find all the DDB files
under “Downloads” on the SIMATIC Customer Support web site:
 http://www.ad.siemens.de/support/html_00/index.shtml
 http://www.ad.siemens.de/csi/gsd
Alternatively, you can obtain the DDB file via modem on +49 (0)911-737972 or at
CompuServe in AUTFORUM (GO AUTFORUM).
Important Features
If you do not have the DDB file to hand, the following table lists the most important
features of the IM 151/CPU.
Tabelle 5-1 Attributes of the Device Database (DDB) File
Feature
DP Keyword to IEC 61158/EN
50170, Volume 2, PROFIBUS
IM 151/CPU
Manufacturer ID Ident_Number 806C
H
806D
H
(FO)
Supports FMS FMS_supp No
Supports 9.6 kbps 9.6_supp Yes
Supports 19.2 kbps 19.2_supp Yes
Supports 45.45 kbps 45.45_supp Yes
Supports 93.75 kbps 93.75_supp Yes
Supports 187.5 kbps 187.5_supp Yes
Supports 500 kbps 500_supp Yes
Supports 1.5 Mbps 1.5M_supp Yes
Supports 3 Mbps 3M_supp Yes
No (FO)
Supports 6 Mbps 6M_supp Yes
No (FO)
