Commissioning and Diagnostics
4-24
ET 200S Interface Module IM 151/CPU
A5E00058783-01
4.7 System Status List (SSL)
Possible System Status Sublists
The following table lists all the possible sublists with the associated sublist extracts
and the SSL IDs.
Details on how to read out the SSL using, for example, SFC 51, and more
information on the contents can be found in the following:
 In the System Software for S7-300/400 reference manual, in the chapter
entitled System and Standard Functions, System Status List SSL
 In the STEP 7 online help system, context-sensitive help on the SFBs/SFCs.
Table 4-13 SSL Sublists of the IM 151/CPU
Sublist
SSL ID
Sublist
Sublist Extract SSL ID
Extract
Module identification W#16#xy11 CPU identification W#16#0111
CPU features W#16#xy12 All features
Features of a group
SSL sublist header information
only
W#16#0012
W#16#0112
W#16#0F12
User memory areas W#16#xy13 Records of all user memory
areas
W#16#0013
System areas W#16#xy14 Records of all system areas W#16#0014
Block types W#16#xy15 Records of all block types
Records of all OBs
W#16#0015
W#16#0115
Status of the module LEDs W#16#xy19 Status of all LEDs
SSL sublist header information
only
W#16#0019
W#16#0F19
Interrupt status W#16#xy22 Record for the specified interrupt W#16#0222
Communication: status data W#16#xy32 Status data for a communication
component
Status data for a communication
component
W#16#0132
W#16#0232
Status of the module LEDs W#16#xy74 Status of all LEDs
Status of an LED
SSL sublist header information
only
W#16#0074
W#16#0174
W#16#0F74
