4-1
ET 200S Interface Module IM 151/CPU
A5E00058783-01
Commissioning and Diagnostics
Configuring the IM 151/CPU with
STEP 7
This chapter outlines how to configure an ET 200S for the IM 151/CPU with
STEP 7
.
Resetting the Memory of the IM 151/CPU
Under certain circumstances you have to reset the memory of the CPU component
of the IM 151/CPU. This chapter describes these circumstances and the procedure
for resetting the memory of the CPU component.
Diagnostic Options
The ET 200S distributed I/O system is designed to make handling and
commissioning as simple as possible. If a fault or an error should occur in spite of
this, you can analyze it using the LEDs, the slave diagnosis and the diagnostic
options in
STEP 7
.
Interrupt Evaluation
To help you evaluate the interrupts of the ET 200S, we will examine the difference
between these and the interrupts of the S7/M7 DP master and other DP masters.
Chapter Overview
In
Section
Contents Page
4.1 Configuring the IM 151/CPU 4-2
4.2 Resetting the Memory of the IM 151/CPU 4-4
4.3 Commissioning and Startup of the ET 200S 4-7
4.4 Diagnostics Using LEDs 4-9
4.5 Diagnostics via the Diagnostic Address with
STEP 7
4-11
4.6 Slave Diagnosis 4-14
4.7 System Status List (SSL) 4-24
