Getting Started - ET 200S-IM 151/CPU Interface Module
A5E00058783-01
8-17
5b
6 Confirm the settings with OK, and close the Setting the PG/PC Interface program.
7 Open the front panel of the S7-300 CPU.
Remove the connector of the programming device cable from the MPI interface of the S7-300
CPU, and put it on the bus connector of the PROFIBUS-DP cable on the S7-300 CPU. Secure
the connector.
Close the front panel of the S7-300 CPU as far as possible.
8 Navigate in SIMATIC Manager to the block container
of the ET 200S.
Select the block container in the left-hand part of the
window.
In SIMATIC Manager, choose the 'RZQORDG
command from the 3/&menu to transfer the
program and the hardware configuration to the
IM 151/CPU.
Click <HVin all the dialog boxes that appear.
The program and configuration are
downloaded from the programming
device to the CPU.
9
Put the mode selector of the IM 151/CPU into the
5813position
The 6723LED of the IM goes out.
The 581LED starts to flash and then
comes on continuously. The 6)LED
comes on.
10
Put the mode selector of the S7-300 CPU into the
5813position
The 6723LED of the S7 goes out.
The 581LED starts to flash and then
comes on continuously. The 6)LED of
the IM goes out.
