Expanding and assigning parameters to the device
6.6 Drives
SIMATIC IPC847E
122 Operating Instructions, 10/2018, A5E43920357-AA
You can find information on the correct mounting location for 5.25" drives in a type A drive
cage under "Permissible expansion for temperature range 0 to 40 °C (Page 100)" and
"Permissible expansion for temperature range 0 to 50 °C (Page 102)", for type B drive cage
in "Permissible expansion for temperature range 0 to 40 °C (Page 114)" and "Permissible
expansion for temperature range 0 to 50 °C (Page 116)".
● There is no drive or any other component in the mounting location for 5.25" components.
● The device is fully disconnected from the line voltage, see "Switching off the device
(Page 60)".
● The device is open, see important information in "Open the device (Page 89)".
● T10 screwdriver
1. Unlock the drive mounting bar together with the blanking plate by pressing laterally
against the surfaces
① and push the drive mounting bar forward from the device in the
direction of the arrow.
