Technical specifications
8.8 Technical specification of the hardware RAID adapter card
SIMATIC IPC847E
160 Operating Instructions, 10/2018, A5E43920357-AA
Technical specification of the hardware RAID adapter card
See the note in "Applicability of technical specifications (Page 149)".
Controller
• SAS Hardware RAID Controller, PCIe x8, RAID 1, 5
• Type: Microsemi ASR3151-4i (independent processor, 1024 MB DDR3 cache)
Adapter
• 1 × Mini SAS HD adapter (SFF-8643 for 4 drives)
Maximum theoretical controller
data rate
• 12 Gbps per port
Memory
• Maintenance-free buffer unit for onboard cache memory
Technical specifications of graphic
See the note in "Applicability of technical specifications (Page 149)".
Graphic controller
• Intel
®
UHD Graphics 630 (GT2)
integrated in processor:
Intel® Core™ i3-8100
Intel® Core™ i5-8500
Intel
®
Core™ i7-8700
• Intel
®
UHD Graphics P630 (GT2)
integrated in processor:
®
®
Graphics memory Dynamic Video Memory Technology, uses 32 MB in main memory
Resolutions/frequencies/colors
• DVI up to 1920 × 1200 pixels at 60 Hz; color depth up to 32-bit/pixel
• DisplayPort up to 4096 × 2304 pixels at 60 Hz; color depth up to 32-bit/pixel
• VGA (VGA via DP to VGA adapter) up to 2560 × 1600 pixels at 60 Hz; color
depth up to 32 bits/pixel
Graphics card (optional) PCIe x16; triple head
You can find information on connection options for monitors with adapters under
"Connecting I/O devices (Page 55)
"
.
• Type: Quadro P400, 2 GB graphics memory
• Maximum resolution:
– 3x DisplayPort 4096 x 2160 at 60 Hz; 32-bit color depth or
– 1x DisplayPort 5120 × 2880 at 60 Hz; 32-bit color depth
– DVI 1920 × 1200 at 60 Hz; 32-bit color depth
– VGA 2048 × 1536 at 60 Hz; 32-bit color depth
