Hardware description
A.2 Internal interfaces
SIMATIC IPC847E
Operating Instructions, 10/2018, A5E43920357-AA
175
A.2.5
Internal interface connector (USB 2.0)
Pin
Name
Meaning
1
VCC
+ 5 V (fused)
2 VCC + 5 V (fused)
3
-Data USB1
Data channel, bidirectional
4 -Data USB3 Data channel, bidirectional
5
+Data USB1
Data channel, bidirectional
6
+Data USB3
Data channel, bidirectional
7
GND
Ground
8
GND
Ground
9
GND
Ground
10
Key
–
A.2.6
Internal interface connector (USB 3.0/USB 2.0)
Pin
Name
Meaning
USB3 (USB3/USB 2.0 contacts)
A1
VCC
+ 5 V (fused)
A2
SSRX-
Data input USB3
A3
SSRX+
Data input USB3
A4
GND
Ground
A5
SSTX-
Data output USB3
A6
SSTX+
Data output USB3
A7
GND
Ground
A8
-Data
Data channel USB2, bidirectional
A9
+Data
Data channel USB2, bidirectional
A10
Reserved
+ 5 V (fused) or ground
USB2 (USB 2.0 contacts)
B1 -Data Data channel USB2
B2
+Data
Data channel USB2
B3
GND
Ground
B4, 5
NC
Open
B6
GND
Ground
B7, 8
NC
Open
B9
VCC
+ 5 V (fused)
B10
NC
Open
