Operating the device
5.4 Operating RAID systems
SIMATIC IPC847E
Operating Instructions, 10/2018, A5E43920357-AA
71
Integrating a new drive into the onboard RAID system
The RAID system is configured in the delivery state so that a new drive must be integrated
manually when a defective drive was replaced.
You can also configure the RAID system in such a way that the new drive is automatically
mounted when the defective drive is replaced.
RAID systems with a hot-spare drive are configured so that the hot-spare drive is
automatically integrated in the event of an error.
Configure "Automatic integration of a new drive" (before replacing a defective drive)
If a new drive is automatically integrated, the new drive is not checked for partition
information or existing data.
All partitions and data of the new drive are deleted without warning.
• Insert only a brand new drive or a drive that is configured as a replacement drive.
• Refer to the controller documentation for instructions on setting up replacement drives.
1. Select "Start" > "Intel" > "Intel Rapid Storage Technology".
2. Select the "Preferences" menu.
3. Go to the "Automatic Rebuild" area and
the "Auto-rebuild on hot plug" option.
Configure "Manual integration of a new drive" (before replacing a defective drive)
The RAID system is configured in the delivery state so that a new drive must be integrated
manually when a defective drive was replaced.
You can configure the manual integration of the drive or check the settings yourself.
1. Select "Start" > "Intel" > "Intel Rapid Storage Technology".
2. Select the "Preferences" menu.
3. Go to the "Automatic Rebuild" area and
the "Auto-rebuild on hot plug" option.
