Siemens SIMATIC IPC847E User Manual

Hardware description
A.6 Assignment of expansion interfaces to the software in the TIA Portal (CP assignment)
SIMATIC IPC847E
Operating Instructions, 10/2018, A5E43920357-AA
193
A.5.4
Memory address assignments
The table describes the assignment of the memory addresses in the delivery state of the
device.
Address
Size
(bytes)
Description of the basic function
Possible alternative
function
from
to
FED1 0000 FED1 7FFF 4k Motherboard resources
FED8 0000
FED1 8FFF
4k
Motherboard resources
FED9 0000 FED1 9FFF 5k Motherboard resources
E000 0000
EFFF FFFF
8k
Motherboard resources
FED2 0000
FED3 FFFF
8k
Motherboard resources
FED9 0000
FED9 3FFF
2k
Motherboard resources
FED4 5000
FED8 FFFF
5k
Motherboard resources
FEE0 0000
FEEF FFFF
8k
Motherboard resources
FED0 0000
FED0 03FF
High precision event timer
D000 0000
FD69 FFFF
1k
Motherboard resources
FD60 0000
FD6C FFFF
1.7 GB
Motherboard resources
FD6F 0000
FDFF FFFF
2 GB
Motherboard resources
FE00 0000
FE01 FFFF
1 GB
Motherboard resources
FE20 0000
FE07 FFFF
3 GB
Motherboard resources
FF00 0000
FFFF FFFF
8 GB
Motherboard resources
FE01 0000
FE01 0FFF
4k
SPI flash Controller
A.6
Assignment of expansion interfaces to the software in the TIA Portal
(CP assignment)
The table below shows the correlation between enclosure labeling of the IPC expansion slots
and the labeling that is used during assignment of interfaces to the software in the TIA
Portal.
Enclosure labeling
TIA Portal
1
X100
2
X101
3
X102
4
X103
5
X104
6
X105
7
X106
8 X107
9
X108
10 X109
11
X110
