Siemens Simatic S7-400 User Manual

IF 964-DP interface module
11.3 Technical specifications
S7-400 Automation System, CPU Specifications
11-4 Manual, 10/2006, 6ES7498-8AA04-8BA0
11.3 Technical specifications
Technical specifications
The IF 964-DP interface module obtains its power from the CPU. The technical
specifications include the necessary current consumption to allow dimensioning of the power
supply unit.
Dimensions and weight
Dimensions
W x H x D (mm)
26 x 54 x 130
Weight 0.065 kg
Performance features
Transmission rate 9.6 Kbps to 12 Mbps
Length of cable
• at 9.6 Kbps
• at 12 Mbps
maximum 1200 m
maximum 100 m
Number of stations ≤125 (depending on the CPU used)
Physical interface characteristics RS-485
Isolation Yes
Voltages, Currents
Power supply supplied by the S7-400
Current consumption from the S7-400 bus
The CPU does not consume any current at 24
V, it only makes this voltage available at the
MPI/DP interface.
Total current consumption of the components
connected to the DP interface, however maximum
of 150 mA
Possible load of the floating 5 V (P5
ext
) Maximum 90 mA
Possible load of the 24 V Maximum 150 mA
Module identifier C
H
Power loss 1 W

Siemens Simatic S7-400 Specifications

General

Programming Language	STEP 7 (LAD, FBD, STL, SCL, GRAPH)
Communication Interfaces	MPI, PROFIBUS
Power Supply	24 V DC, 120/230 V AC (Power supply modules are separate and chosen based on system requirements)
Operating Temperature	0°C to 60°C
Mounting	Rack mounting
Processor	CPU 412-1, CPU 414-2, CPU 416-2, CPU 417-4 (Different CPUs offer varying performance and features)
Relative Humidity	5 to 95% (non-condensing)
