Technical information
7.5 Information on insulation tests, protection class and degree of protection
IFP V2, IFP V2 PRO, IFP V2 ETH
Operating Instructions, 03/2023, A5E46641410-AE
95
Type of condition
Mounting position
Permitted range
Temperature built-in de-
vices,
Mounting in portrait for-
mat
Vertical
0 ... 40 °C
Inclined, maximum inclination
35°
0 ... 35 °C
Temperature PRO devices
1
Vertical
0 ... 45 °C
Inclined, maximum inclination
45°
0 ... 45 °C
Temperature Transceiv-
er Unit
vertical, interfaces facing down-
ward
0 ... 50 °C
Air pressure, operating
elevation
1140 ... 795 hPa, corresponds to an elevation of -1000 ... 2000 m
Relative humidity
10 ... 90 %, no condensation
2
Pollutant concentration
According to ANSI/ISA-71.04-2013 severity level G3
1
Only mounting in the standard mounting position is permitted for PRO devices
2
Built-in devices: No condensation on the rear of the device,
PRO devices: No condensation inside the enclosure,
Transceiver Unit No condensation all-round
Observe the information in section "Notes on use (Page 28)" and for IFPs the information on
the mounting positions:
• Permitted mounting positions for built-in devices (Page 34)
• Permitted mounting positions for PRO devices (Page 39)
Note
All other system components connected to the device, such as the power supply, must also
be suited to the respective operating conditions.
7.5 Information on insulation tests, protection class and degree of
protection
Insulation test
The insulation strength is demonstrated in the type test with the following test voltages in
accordance with IEC 61010-2-201:
Circuit
Insulation tested with (type test)
Rated voltage Ue 24 V
707 V DC to other circuits / to ground
Ethernet socket
1
1500 V AC
1
Check applies to interface X1 Ethernet, not to X71 Ext-Link
