Siemens SIMOTICS S-1FT2 - Rotating Motor Connectors

Current-carrying capacity for power and signal cables
The current-carrying capacity of PVC/PUR-insulated copper cables is speci󹪝ed for routing types
B1, B2 and C under continuous operating conditions in the table with reference to an ambient
air temperature of 40° C. For other ambient temperatures, the values must be corrected by the
factors from the "Derating factors" table.
Table 7-1 Cable cross-section and current-carrying capacity
Cross-section in mm²

Current-carrying capacity rms; AC 50/60Hz or DC for routing type
B1 in A B2 in A C in A
Electronics (according to EN 60204-1)
0.20 - 4.3 4.4
0.50 - 7.5 7.5
0.75 - 9 9.5
Power (according to EN 60204-1)
0.75 8.6 8.5 9.8
1.00 10.3 10.1 11.7
1.50 13.5 13.1 15.2
2.50 18.3 17.4 21
4 24 23 28
6 31 30 36
10 44 40 50
16 59 54 60
Table 7-2 Derating factors for power and signal cables
Ambient air temperature in °C Derating factor according to EN60204-1 TableD1
30 1.15
35 1.08
40 1.00
45 0.91
50 0.82
55 0.71
60 0.58
7.3.1.2 Rotating the connector on the motor
You can rotate power connectors and signal connectors within a limited range of angles.
Use a suitable socket connector to rotate the angle plug.
Connecting
7.3System integration
SIMOTICS S-1FT2 synchronous motors for SINAMICS S120
