3.3.10 Configuring Mode CAE4/CAE5 -- Setting UNI Module(s)
The measuring ranges for the various selectable signal transmitters for slot 2 (AE4) or slot 3
(AE5) can be defined in these menus and fine adjustment performed if necessary.
The CAE4 menu is only offered in the selection level if AEF is set at uni._ or uni.
in the config-
uring mode hdEF.
The CAE5 module is only offered in the selection level if AE5 is set to uni._ or uni.
in the con-
figuring mode hdEF.
In the uni._ selection the corresponding measuring signal is set to 0 in the event of a sensor
failure, in uni.
selection to 1.
An error message will appear if the UNI module is not available: OP.. / 2,3..
The following parameters are available in the CAE4/CAE5 menus for setting the measur-
ing range and adjustment:
Display
dd2 para-
meter
Parameter
meaning
Display dd1
Parameter
range
Meaning of parame-
ter
Factory
setting
Display unit Display/func-
tion only at
:
SEnS Sensor type Mv.
tc.in
tc.EH
Pt.4L
Pt.3L
Pt.2L
r.- -
r.
Mv signal
Thermocouple internal
reference point
Thermocouple external
Reference point
PT100 4--wire
PT100 3--wire
PT100 2--wire
Resistor < 600 Ω
Resistor < 2.8 kΩ
Mv.
unit Temperature unit _C
_F
_AbS
Degrees Celsius
Degrees Fahrenheit
Degrees Kelvin
_C
tc Thermocouple
type
L,J,H,S,b,r,E
n,t,U
Lin
Type L,J,K,S,B,R,E,N,T,U
Any type (without li-
nearization)
L SEnS=tc.in,
tc/EH
tb
1)
Temperature refe-
rence point
0.0...400.0 50.0 _C, _F, _ AbS SEnS=tc.EH
Mr Line resistance 0.00...100.00 10.00 ohms SEnS=Pt.2L
Cr Calibration line re-
sistance
Dif ference to
Mr
ohms SEnS=Pt.2L
MP Decimal point
measuring range
_.------ to ____ ___.--
MA
2)
Range start --1999...19999 0.0 Mv, _C, _F, _AbS
ME
2)
Range end --1999...19999 100.0 depending on set-
ting SEnS
CA
3)
Calibration range
start
curr. measured
value
+/-- ΔA
CE
3)
Calibration range
end
curr. measured
value
+/-- ΔE
PC
4)
Preset calibration no,YES,no C
SEnSE!=r._, r.
1)
If no specified type of thermocouple is selected with tc=Lin, parameter tb is inactive.
2)
The set range normalizes the measured value to 0 to 1 for transfer to the switchable range. If the physical operating
display of the measuring value is to be made, the assigned display dd, dA, dE must be set accordingly.
3)
For SEnS=r._/r. the unit of the CA/CE display is in %.
4)
Ef fect PC for SEnS = Mv., tc.in, tc.EH, Pt.2L, Pt.3L, Pt.4L.
PC=no C is displayed with A=E=0. It is not possible to switch to ”YES” with tA2.
PC=no is displayed by adjusting CA/CE (fine calibration). It is possible to switch to ”YES”.
Fine calibration is reset by pressing the Enter key (3s). (ΔA=ΔE=0, PC=no C).
