1 Technical Description
1.5 Functional Description
1.5.7 Basic Functions (Arithmetic blocks b)
Manual
44
SIP ART DR24 6DR2410
C79000-G7476-C153-03
1.5.7.2 Mathematical Functions
Absolute value
A=|E1|
Adder
A = E1 + E2 + E3
with default: A = E1 + E2
Divider
A=E1/E2
with default: A = 1/E2
Definitions:
0/number = 0, 0/0 = 0,
number/0 = 10
19
E2 can be limited by E3. This pre-
vents the output jumping between
+10
19
and --10
19
at lower values of E2
(about 0) and becomes very rest-
less due to the great steepness. If you
do not want this limit, E3 must be as-
signed 0.000.
E3 > 0
Minimum value limiting of E2 to the
value of E3 (division only in the 1st
and 4th quadrants).
E3 < 0
MaximumevaluationofE2tothe
value of E3 (division only in the 2nd
and 3rd quadrants).
E3 = 0
No limiting of E2 (division in all 4
quadrants with pole position at
E2 = 0).
Decadic logarithmer
A = lg E1 E1 > 0
E1 ≤ 0, A = --10
19
ncon
A
E
n
.A
∩
---
∩ .1
b.F
--
AbS
0.000
ncon
ncon
+
+
+
.A∩
b.F
--
∩ .1
∩ .2
∩ .3
n
---
Add
1.000
0.001
ncon
E1
E2
.A∩
b.F
--
∩ .1
∩ .2
∩ .3
n
---
div
E1
E2
with E1 = -1
E1
E2
with E1 = -1
A
-1
-.2
-3
E2
--E3
.
2
3
1
3
.
2
1
E1
E2
with E1 = -1
E1
E2
with E1 = -1
A
E2
-2
-3
-1
-1
E3
3
.
2
1
.
2
1
3
ncon
lg
n
.A
∩
---
∩ .1
b.F
--
LG
