Siemens SIPROTEC 7UT63 series User Manual

4 Technical Data
434
7UT613/63x Manual
C53000-G1176-C160-2
4.1.10 Constructional Details
1)
With shipping brace
Housing 7XP20
Dimensions see dimensional drawings in the technical
data section
Weight (maximum number of components ) approx.
7UT613
In surface-mounted housing, size
1
/
2
In flush-mounted housing, size
1
/
2
13.5 kg (29.8 lb)
8.7 kg (19.2 lb)
7UT633
In surface-mounted housing, size
1
/
1
In surface-mounted housing, size
1
/
1
1)
In flush-mounted housing, size
1
/
1
22.0 kg (48.5 lb)
25.3 kg (55.8 lb)
13.8 kg (30.4 lb)
7UT635
In surface-mounted housing, size
1
/
1
In surface-mounted housing, size
1
/
1
1)
In flush-mounted housing, size
1
/
1
22.7 kg (50 lb)
26.0 kg (57.3 lb)
14.5 kg (32 lb)
Degree of protection acc. to IEC 60529
For the device in surface-mounted housing IP 51
For the device in flush-mounted housing
Front IP 51
Back IP 50
For human safety IP 2x with closed protection cover
UL-certification conditions Type 1 for front panel mounting
Surrounding air temperatur:
tsurr: max 70
o
C, normal operation
