4 Technical Data
484
7UT613/63x Manual
C53000-G1176-C160-2
Processing Times in TICKS required by the Individual Elements
Element Number of TICKS
Module, basic requirement 5
Each input from the 3rd additional input for generic blocks 1
Connection to an input signal 6
Connection to an output signal 7
Additional for each chart 1
Switching Sequence CM_CHAIN 34
Status Memory for Restart D_OFF_MEMO 6
Feedback Loop LOOP 8
Decode Double Point DM_DECODE 8
Dynamic OR D_OR 6
Addition ADD 26
Substraction SUB 26
Multiplication MU 26
Division IV 54
Root Extractor SQUARE_ROOT 83
