Remote Operation : PA
Page 32 SITRANS Probe LU (PROFIBUS PA) – INSTRUCTION MANUAL 7ML19985JB02
Acyclic Data
SITRANS Probe LU supports up to four simultaneous connections by a Class 2 Master
(C2 connection). It supports one connection by a Class 1 Master (C1 connection).
In order for a Class 1 Master to read parameters from an instrument, it needs to know the
slot and absolute index of the parameter.
The parameters are all listed in SIMATIC PDM under Help. If you do not have SIMATIC
PDM, you can download the DD and reference the HTML help file directly.
S:34
Factory calibration for the
device has been lost.
Repair required: contact your
local Siemens representative.
4
2
S:35
Factory calibration for the
device has been lost.
Repair required: contact your
local Siemens representative.
3
S:36
Factory calibration for the
device has been lost.
Repair required: contact your
local Siemens representative.
4
S:37
Ultrasonic module hard-
ware defect: Unable to col-
lect profile.
Repair required: contact your
local Siemens representative.
5
S:38
Ultrasonic module hard-
ware failure: unable to cal-
culate distance
measurement.
Repair required: contact your
local Siemens representative.
6
S:39
Transducer temperature
sensor failure.
Reset power. If fault persists,
contact your local Siemens rep-
resentative: repair required.:.
7
S:40
Transducer temperature
too high.
Relocate device and/or lower
process temperature enough to
cool device. Inspect for heat-
related damage and contact
your local Siemens representa-
tive if repair is required.
5
0
S:41
Transducer temperature
too low.
Relocate device and/or raise
process temperature enough to
warm device. Inspect for dam-
age and contact your local Sie-
mens representative if repair is
required.
1
S:42
Factory calibration for the
transducer temperature
sensor has been lost.
Repair required: contact your
local Siemens representative.
2
LCD
display
Cause/symptom (cont’d) Corrective Action (cont’d) Byte Bit

Siemens sitrans PROBE LU Specifications

General

Measuring Principle	Ultrasonic
Communication	HART
Output	4 to 20 mA
Power Supply	12 to 30 V DC
Process Temperature	-40 to 80 °C
Enclosure Rating	IP68
Material	PVDF
Ambient Temperature	-40 to 70 °C
Measurement Range	0.25 to 12 m (0.8 to 39 ft)
