Page 64 SITRANS Probe LU (PROFIBUS PA) – INSTRUCTION MANUAL 7ML19985JB02
mmmmm
G: Data Map
Analog Input Function Blocks: AIFB1 and AIFB2
Each of the two Analog Input Function Blocks can be set up to return Level, Distance, or
Volume. Within the function blocks, the values are scaled according to the user
requirement.
Relative
Index
Name Access Structure Type
0 Block Object r
Reserved UNSIGNED_INTEGER (1)
Block Object INTEGER (1)
Parent Class INTEGER (1)
Class INTEGER (1)
DD Reference UNSIGNED_INTEGER(4)
DD Revision UNSIGNED_INTEGER(2)
Profile INTEGER (2)
Profile Revision INTEGER (2)
Execution time UNSIGNED_INTEGER (1)
Number of Parameters UNSIGNED_INTEGER(2)
Address of View 1 UNSIGNED_INTEGER(2)
Number of views UNSIGNED_INTEGER(1)
1 ST REV r Value UNSIGNED_INTEGER(2)
2 Tag r/w Value ASCII(32)
3 Strategy r/w Value UNSIGNED_INTEGER(2)
4 Alert Key r/w Value UNSIGNED_INTEGER (1)
5 Target Mode r/w Value UNSIGNED_INTEGER (1)
6Mode Blockr
Actual Mode UNSIGNED_INTEGER (1)
Permitted Modes UNSIGNED_INTEGER (1)
Normal Mode UNSIGNED_INTEGER (1)
7
Alarm Sum-
mary
r/w
Current States UNSIGNED_INTEGER (2)
Unacknowledged UNSIGNED_INTEGER (2)
Unreported UNSIGNED_INTEGER (2)
Disabled UNSIGNED_INTEGER (2)
8
Batch Informa-
tion
r/w
Batch ID UNSIGNED_INTEGER(4)
Batch Unit UNSIGNED_INTEGER (2)
Batch Operation UNSIGNED_INTEGER(2)
Batch Phase UNSIGNED_INTEGER(2)
10 OUT r/w
Output Value FLOAT (2)
Quality UNSIGNED_INTEGER (1)
Status UNSIGNED_INTEGER (1)
11 PV Range r/w
Upper FLOAT (2)
Lower FLOAT (2)
