7ML19985JB02 SITRANS Probe LU (PROFIBUS PA) – INSTRUCTION MANUAL Page 73
mmmmm
H: Parameters
Appendix H: Parameter Descriptions
SITRANS Probe LU (PROFIBUS PA): parameter menus
The parameters are grouped in menus according to function. Submenus, arranged on
four levels, give access to associated features and options.
Some menus are accessible in PDM only via pull-down menus: in those cases, directions
are given beside the individual parameter.
Not all menus are accessible via the handheld programmer. Menus that are accessible
via the handheld programmer are preceded by a number (applicable only to the handheld
programmer).
1. Identification
Operation Unit
Tag
Text that can be used in any way, for example as a unique label for a field device
in the plant.
Description
Text that is associated with the Field Device. This text can be used by the user in
any way. There is no specific recommended use.
Message
Text that is associated with the FIeld Device. This text can be used by the user in
any way. There is no specific recommended use.
1.2. Configuration
1.2.1. Device Address (default 126)
The unique address of the device on the network (also called PROFIBUS address).
Open the menu Device – Set Address.
Notes:
• For Quick Access to parameters via the handheld programmer, press the mode key
to activate PROGRAM mode, then key in the menu number. (For more details, see
The handheld programmer on page 17.)
• Values shown in the tables below can be entered via the handheld programmer.
• Default values are indicated by an asterisk (*) in the tables, unless explicitly stated.
Values
0 - 126

Siemens sitrans PROBE LU Specifications

General

Measuring Principle	Ultrasonic
Communication	HART
Output	4 to 20 mA
Power Supply	12 to 30 V DC
Process Temperature	-40 to 80 °C
Enclosure Rating	IP68
Material	PVDF
Ambient Temperature	-40 to 70 °C
Measurement Range	0.25 to 12 m (0.8 to 39 ft)
