Page 66 SITRANS Probe LU (PROFIBUS PA) – INSTRUCTION MANUAL 7ML19985JB02
mmmmm
G: Data Map
Level Transducer Block
This is the main transducer block for the device. (A second block is for internal use only.)
Relative
Index
Name Access Structure Type
0 Block Object r
Profile Parameter UNSIGNED_INTEGER (1)
Block Object INTEGER (1)
Parent Class INTEGER (1)
Class INTEGER (1)
DD Reference UNSIGNED_INTEGER(4)
DD Revision UNSIGNED_INTEGER(2)
Profile INTEGER (2)
Profile Revision INTEGER (2)
Execution Time UNSIGNED_INTEGER (1)
Number of Parameters UNSIGNED_INTEGER(2)
Index of View 1 UNSIGNED_INTEGER(2)
Number of views UNSIGNED_INTEGER(1)
1
Static Revision
Number
r Value UNSIGNED_INTEGER(2)
2 Tag r/w Value ASCII(32)
3 Strategy r/w Value UNSIGNED_INTEGER(2)
4 Alert Key r/w Value UNSIGNED_INTEGER (1)
5 Target Mode r/w Value UNSIGNED_INTEGER (1)
6Mode Block
r Actual Mode UNSIGNED_INTEGER (1)
r/w Permitted Modes UNSIGNED_INTEGER (1)
r/w Normal Mode UNSIGNED_INTEGER (1)
7 Alarm Summary r/w
Current States UNSIGNED_INTEGER (2)
Unacknowledged UNSIGNED_INTEGER (2)
Unreported UNSIGNED_INTEGER (2)
Disabled UNSIGNED_INTEGER (2)
8
PV (Level/
Volume)
r
Value (Level/Volume) FLOAT (2)
Status (Level/Volume) INTEGER (1)
9
PV Units (Level/
Volume)
r/w Value INTEGER (2)
10
Measured Value
(Level)
r Value FLOAT (2)
11 Level Units r/w Value UNSIGNED_INTEGER (2)
12 Sensor Value r Value FLOAT (2)
13 Sensor Units r/w Value INTEGER (2)
