Page 42 SITRANS Probe LU (PROFIBUS PA) – INSTRUCTION MANUAL 7ML19985JB02
mmmmm
D: Local Operation
Appendix D: programming via the
handheld programmer
Although the complete range of parameters is only accessible via PDM
1
, you can access
and adjust many of the parameters via the Siemens infrared handheld programmer.
• For the complete list of parameters, see
Appendix H: Parameter Descriptions on
page 73.
• Appendix E: LCD menu structure on page 49 gives a list of all parameters accessible
via the handheld programmer, preceded by the menu number.
Parameter Menu Structure
The parameters are organized into function groups, and arranged in a 4-level menu
structure. For example:
1. Identification
1.2. Configuration
1.2.2. Remote Lock.
The LCD Display
Details on the LCD display are given in Startup on page 16.
Using the handheld programmer
Basic instructions on using the handheld programmer start on page 17, and on doing a
Quick Setup start on page 19.
The following pages give details on how to programme some of the more complex
SITRANS Probe LU parameters via the handheld programmer.
To activate PROGRAM mode, point the handheld programmer at the display (from a
maximum distance of 600 mm [2 ft]), and press the Mode key (see illustration on
page 17).
1.
Please see Remote operation via PROFIBUS PA on page 22.
Note: For Quick Access to parameters via the handheld programmer, press the mode
key to activate PROGRAM mode, then key in the menu number.

Siemens sitrans PROBE LU Specifications

General

Measuring Principle	Ultrasonic
Communication	HART
Output	4 to 20 mA
Power Supply	12 to 30 V DC
Process Temperature	-40 to 80 °C
Enclosure Rating	IP68
Material	PVDF
Ambient Temperature	-40 to 70 °C
Measurement Range	0.25 to 12 m (0.8 to 39 ft)
