Smartgen ALC700 SERIES User Manual

ALC700 Series Light Tower Set Controller
ALC700 Series Light Tower Set Controller 2018-03-02 Version 1.4 Page 40 of 51
8.5 SENSOR SELECTION
No.
Items
Contents
Remark
1
Temperature
Sensor
0 Not used
1 Digital closed
2Digital open
3 VDO 120 degrees C
4 Datcon high
5 Datcon low
6 SGX 120 degrees C
7 Cummins
8 SGH 120 degrees C
9 Curtis
10 SGD 120 degrees C
11 Pt100
12 User defined
The range of user-defined
resistor type sensor is
0-999 Ohm; by default
VDO 120 degrees C
sensor curve is selected.
User defined sensor curve
can be set via PC
software.
2
Oil pressure
Sensor
0 Not used
1 Digital closed
2 Digital open
3 VDO 5 bar
4 VDO 10 bar
5 Datcon 5 bar
6 Datcon 10 bar
7 Datcon 7 bar
8 SGX 10 bar
9 CMB812
10 SGH 10 bar
11 Curtis
12 SGD 10 bar
13 User defined
The range of user-defined
resistor type sensor is
0-999 Ohm; by default
VDO 10 bar sensor curve
is selected. User defined
sensor curve can be set
via utility software.
3
Fuel Level
Sensor
0 Not used
1 Digital closed
2 Digital open
3 VDO Ohm range (10-180)
4 VDO Tube type (90-0)
5 US Ohm range (240-33)
6 GM Ohm range (0-90)
7 GM Ohm range Ohm range (0-30)
8 Ford (73-10)
9 NKZR12/24-1-04 Ohm range (100-0)
10 User defined
The range of user-defined
resistor type sensor is
0-999 Ohm; by default
VDO 0hm range
(10-180) sensor curve is
selected. User defined
sensor curve can be set
via utility software.

Smartgen ALC700 SERIES Specifications

General

Brand	Smartgen
Model	ALC700 SERIES
Category	Controller
Language	English
